| Segment ＼ Type |
Smoke Removing Screen |
150 |
300 |
400 |
600 |
800 |
1000 |
1200 |
1500 |
| MOTOR
Output(W) |
80W |
80W |
150W |
200W |
450W |
650W |
750W |
1100W |
1500W |
| Number
of Motor Poles (P) |
4P |
4P |
4P |
4P |
4P |
4P |
4P |
4P |
4P |
| Bracket
included Set (kg) |
6.7kg |
21.15kg |
26.6kg |
30.5kg |
46.3kg |
62.2kg |
71.5kg |
92.4kg |
95kg |
| Speed of Revolution (RPM) |
43.7 |
25.3 |
32.4 |
29.3 |
20.6 |
20.6 |
19.5 |
19.5 |
19.5 |
| Rate of Speed Reduction |
39.9 |
69 |
53.9 |
59.7 |
84.8 |
84.8 |
89.6 |
89.6 |
89.6 |
| Number of Chains and Chain Gear Teeth |
RS35x42T |
RS40x43T |
RS40x43T |
RS40x59T |
RS50x59T |
RS60x54T |
RS60x54T |
RS60x49T |
RS80x49T |
| TORQUE(kg/m) |
1.78 |
3.08 |
4.50 |
6.64 |
21.27 |
30.73 |
37.46 |
54.94 |
74.92 |
| Speed Reduction Rate of Chain Gear |
42T/13T |
43T/10T |
43T/10T |
59T/10T |
59T/10T |
54T/9T |
54T/10T |
49T/9T |
49T/9T |
| Rated Hour (min.) |
10 |
10 |
10 |
10 |
13 |
15 |
15 |
15 |
15 |
| Speed Reduction in Total |
129 |
296.7 |
231.7 |
352 |
500.3 |
508.8 |
483.8 |
487.8 |
487.8 |
| Maximum Wind Capability |
4"(104.3mm) |
90 |
150 |
320 |
440 |
|
|
|
|
|
| 5"(139.8mm) |
|
|
300 |
420 |
620 |
|
|
|
|
| 6"(165.2mm) |
|
|
|
400 |
600 |
830 |
|
|
|
| 8"(216.3mm) |
|
|
|
|
|
800 |
1100 |
|
|
| 10"(267.4mm) |
|
|
|
|
|
|
1000 |
1200 |
1540 |
| 12"(318.5mm) |
|
|
|
|
|
|
|
1100 |
1500 |
| Can be used as a Fire-Preventing Door |
|
X |
O |
O |
O |
O |
O |
O |
O |
